NOTES
CURRENT BEST CUT SETTINGS
WHEN OPENING SVG’S – SELECT TOP OPTION 96UNITS/in
INKSCAPE TIPS
Ctrl + Shift R – Crop image to Cut area MUST DO
Cleaning the lens (tightening the cap back on, alignment of the mirror/tube)
K40 Chinese Lazer Cutter – Getting one up and running.
Sort out the Grounds !!!!
Plug it in and fire it up to see if everything turns on.
K40 Whisperer USB Driver Setup (scorchworks.com)
Works well but not cutting Square
Spectrum Noir Brown – EB4
Could be the lazer – https://www.reddit.com/r/lasercutting/comments/3v8nry/k40_cuts_not_quite_square/
Or the Arm – https://www.reddit.com/r/lasercutting/comments/3zx2xx/k40_straightening_the_xaxis_gantry/
X axis Gantry arm way off, no where near square to Y axis rail.
photos >>>>>>>>
FIXED….
Best Mirror alignment vid – https://www.youtube.com/watch?v=6Bcgo-CoBAs
TOP TIP … MAKE SURE YOU PRESS CTRL SHFT & R TO SHRING TO IMAGE
