Notes

How to Centre a Youtube Video with HTML

SHOUTOUTS

https://easyeda.com/

https://web.archive.org/web/20200222182704/http://mylkstuff.com/

Pin 1 is power ( datasheet recommends a 100uf power filter cap. Pin 2 is the output (through a 470uf cap). Pin 3 is for standby which isn’t needed in a guitar amp so can be left unconnected and Pin 4 is input ( through a 10nf cap). Pins 5,7 & 8 are not connected and  Pin 6 plus pins 9-16 all go to ground (datasheet recommends connecting pins 9-16 to a heat sink). Thats it, 1 chip 3 caps and you have a decent sounding working amplifier, even without adding a buffer or booster.

Retro Pie

KIOSK MODE _ HOW TO REMOVE

K40 Chinese Lazer Cutter – Getting one up and running.

Sort out the Grounds !!!!

Plug it in and fire it up to see if everything turns on.

K40 Whisperer USB Driver Setup (scorchworks.com)

https://inkscape.org/release/1.0.2/windows/64-bit/

Works well but not cutting Square

Could be the lazer – https://www.reddit.com/r/lasercutting/comments/3v8nry/k40_cuts_not_quite_square/

Or the Arm – https://www.reddit.com/r/lasercutting/comments/3zx2xx/k40_straightening_the_xaxis_gantry/

X axis Gantry arm way off, no where near square to Y axis rail.

photos >>>>>>>>

FIXED….

Best Mirror alignment vid – https://www.youtube.com/watch?v=6Bcgo-CoBAs

TOP TIP … MAKE SURE YOU PRESS CTRL SHFT & R TO SHRING TO IMAGE
